Orbital hydraulic motor TG series
Characteristics
- Technology
- orbital
- Other characteristics
- industrial, flange-mount
- Pressure
-
Max.: 276 bar
(4,003 psi)Min.: 120 bar
(1,740 psi) - Rotational speed
-
Max.: 425 rpm
(2,670.35 rad.min-1)Min.: 115 rpm
(722.57 rad.min-1) - Torque
-
Max.: 1,380 Nm
(1,017.84 ft.lb)Min.: 530 Nm
(390.91 ft.lb) - Displacement
-
Max.: 625 cm³
(21.13 US fl oz)Min.: 195 cm³
(6.59 US fl oz)
Description
Data and measurements may differ between makes. Check our data sheet to ensure that the motor is suitable for the use where it is built-in.
TG series motor integrates the advanced Geroler gear set, designed for high speed.
Distribution flow and high pressure, and with good stability at low speed, while maintaining a high volume efficiency. Are characteristicr engine with low friction and internal leakage, maintains efficiency throughout the life of the engine.
Geroler engine with low friction and internal leakage, maintains efficiency throughout the life of the engine.
Flange, gates and shaft options.
